SUPER-G® Multi-NIP™
SUPER-G® MultiNIP™ roll stands offer the most advanced sheet production tool available throughout the industry.
The many patented design features are complimented by PTi’s patented roll toggle design assuring a four (4) point roll gap seating. Key benefits include high clarity and ultra low orientation for extremely flat sheet production. MultiNIP™ roll stands are available in Vertical, J-Stack or Horizontal arrangements.
Thermal Analysis
The charts listed below show the average sheet temperature as the sheet passes through the unique roll stand. The analyses examined 80, 40 and 10 mil sheet thicknesses at production rates of 2,000, 3,000 and 4,000 lbs/hr for unfilled PP resin at 55 inch sheet widths. In each case the data reveals the achievement of a rapid cooling rate while maintaining balanced average web temperatures. This results in the production of a high quality 'stress free' sheet ideal for many demanding sheet applications including Form, Fill & Seal. Comparative analyses were performed using much larger roll stand configurations as a benchmark. In each case the Super G Multi-Nip™ out performed these benchmark cases.
-
Multi-patented technology assures all rolls are properly nipped for optimal performance
-
High capacity thermal ability provides uniform core temperature ideal for Form, Fill & Seal applications
-
Multi-roll arrangement yields ultra-low sheet orientation (i.e.; stress-free production)
-
Compact configuration minimizes system footprint
-
High quality sheet aesthetics result from the all-nipping rolls
Features
Roll stand Options
-
Spare Temperature Control Circuit
-
Hydraulic Roll Actuation
-
Boosted Air Roll Actuation
-
AUTOGAP™ Servo Hydraulic Roll Gap Adjustment
-
Telescoping Conveyors for Fixed Downstream equipment
-
Motorized Roll Gap Adjustment
-
Motorized Height Adjustment
-
Air Knife System for Thin Gauge (shown)
-
Pneumatic Start-Up Leader Winder
-
Water Cooled Pull Rolls, Idler Rolls
-
Auxiliary Cooling Rolls
OFFERING YOU THE BEST SOLUTION FOR YOUR EXTRUSION LINE
Processing Technologies International (PTi) is a global leader in high-performance sheet extrusion machinery. Engineered to exact standards, PTi systems feature innovative design solutions that deliver superior equipment performance and consistently produce sheet goods that meet the industry’s highest quality standards.
PTi offers a comprehensive range of products and services designed to support today’s sheet producers and the evolving demands of the future. While this overview highlights many available configurations and capabilities, it represents only a portion of the customized extrusion solutions PTi provides for a wide variety of applications.
